ELECTRICAL ENCLOSURES
| Height" | Depth" | Length" | Catalog Number | Description | Weight | List Price | UPC_12Digit |
|---|---|---|---|---|---|---|---|
| 4 | 4 | 12 | S1-44P | S/S PULL THRU WIREWAY TYPE 4X | 7 | 192.96 | 806101019411 |
| 4 | 4 | 24 | S2-44P | S/S PULL THRU WIREWAY TYPE 4X | 12 | 262.30 | 806101019428 |
| 4 | 4 | 36 | S3-44P | S/S PULL THRU WIREWAY TYPE 4X | 17 | 323.04 | 806101019435 |
| 4 | 4 | 48 | S4-44P | S/S PULL THRU WIREWAY TYPE 4X | 21 | 381.84 | 806101019442 |
| 4 | 4 | 60 | S5-44P | S/S PULL THRU WIREWAY TYPE 4X | 26 | 432.70 | 806101019459 |
| 4 | 5 | 120 | S10-44P | S/S PULL THRU WIREWAY TYPE 4X | 52 | 718.00 | 806101019466 |
| 4 | 4 | S4-45L | S/S 45L FOR PULL THRU WIREWAY TYPE 4X | 3 | 194.00 | 806101019480 | |
| 4 | 4 | S4-90P | S/S 90L FOR PULL THRU WIREWAY TYPE 4X | 5 | 194.00 | 806101019473 | |
| 4 | 4 | S4-BCP | S/S BOX CONNECTOR FOR PULL THRU WIREWAY TYPE 4X | 1 | 44.68 | 806101019527 | |
| 4 | 4 | S4-BHP | S/S BRACKET HANGER FOR PULL THRU WIREWAY TYPE 4X | 1 | 26.43 | 806101019541 | |
| 4 | 4 | S4-DHP | S/S DROP HANGER FOR PULL THRU WIREWAY TYPE 4X | 1 | 40.52 | 806101019534 | |
| 4 | 4 | S4-EPP | S/S END PLATE PULL THRU WIREWAY TYPE 4X | 1 | 33.74 | 806101019503 | |
| 4 | 4 | S4-N6P | S/S 6 IN. NIPPLE FOR PULL THRU WIREWAY TYPE 4X | 3 | 133.12 | 806101019510 | |
| 4 | 4 | S4-TP | S/S TEE FOR PULL THRU WIREWAY TYPE 4X | 6 | 230.48 | 806101019497 | |
| 6 | 6 | 12 | S1-66P | S/S PULL THRU WIREWAY TYPE 4X | 10 | 262.30 | 806101019558 |
| 6 | 6 | 24 | S2-66P | S/S PULL THRU WIREWAY TYPE 4X | 18 | 351.92 | 806101019565 |
| 6 | 6 | 36 | S3-66P | S/S PULL THRU WIREWAY TYPE 4X | 24 | 440.20 | 806101019572 |
| 6 | 6 | 48 | S4-66P | S/S PULL THRU WIREWAY TYPE 4X | 32 | 537.14 | 806101019589 |
| 6 | 6 | 60 | S5-66P | S/S PULL THRU WIREWAY TYPE 4X | 40 | 627.68 | 806101019596 |
| 6 | 6 | 120 | S10-66P | S/S PULL THRU WIREWAY TYPE 4X | 78 | 1060.56 | 806101019602 |
| 6 | 6 | S6-45L | S/S 45L FOR PULL THRU WIREWAY TYPE 4X | 6 | 238.00 | 806101019626 | |
| 6 | 6 | S6-90P | S/S 90L FOR PULL THRU WIREWAY TYPE 4X | 8 | 238.00 | 806101019619 | |
| 6 | 6 | S6-BCP | S/S BOX CONNECTOR FOR PULL THRU WIREWAY TYPE 4X | 1 | 53.56 | 806101019664 | |
| 6 | 6 | S6-BHP | S/S BRACKET HANGER FOR PULL THRU WIREWAY TYPE 4X | 3 | 36.83 | 806101019688 | |
| 6 | 6 | S6-DHP | S/S DROP HANGER FOR PULL THRU WIREWAY TYPE 4X | 2 | 54.99 | 806101019671 | |
| 6 | 6 | S6-EPP | S/S END PLATE PULL THRU WIREWAY TYPE 4X | 3 | 41.02 | 806101019640 | |
| 6 | 6 | S6-N6P | S/S 6 IN. NIPPLE FOR PULL THRU WIREWAY TYPE 4X | 5 | 179.43 | 806101019657 | |
| 6 | 6 | S6-TP | S/S TEE FOR PULL THRU WIREWAY TYPE 4X | 10 | 318.70 | 806101019633 |
